The Vault Room is the apex of protection in IT Shielding, meticulously engineered to ensure high availability down to the last detail. From the hard ducts for cable and pipe insertion to the rigorously tested security doors equipped with various access control systems, every aspect is carefully crafted. It stands as the state-of-the-art solution to elevate your data infrastructure.
Vault Room's modular design
By embracing a modular design, the Vault Room can be effortlessly adjusted and expanded. Every modular component, from the panels to the cooling system, is crafted for seamless integration. This not only simplifies the installation and configuration process but also allows for efficient scalability, enabling the data center to grow alongside the company's needs.
Vault Room: Minimizing TCO and TTM
The modular design allows for seamless and scalable expansion, eliminating the necessity for hefty initial investments in oversized infrastructure, thus reducing TCO (Total Cost of Ownership). Furthermore, modularity facilitates swift implementation, streamlining the installation process and cutting down TTM (Time to Market).
up to
40%
reduction in TTM
up to
30%
reduction in TCO
Vault Room: a pre-fabricated product
The Vault Room is pre-fabricated, offering an easy and clean setup on-site with minimal site preparation. Its pre-fabricated design allows for swift installation, reducing downtime and disruptions to ongoing operations. With components precisely engineered off-site, the Vault Room ensures consistency and quality in construction, while also minimizing the need for extensive on-site assembly. This streamlined setup process not only saves time but also reduces costs associated with traditional construction methods. Overall, the pre-fabricated nature of the Vault Room enables efficient deployment, making it an ideal solution for businesses seeking rapid implementation without compromising on security or reliability.
Vault Room infrastructure
The Vault Room's IT infrastructure boasts a seamlessly integrated design, all within a single footprint. This holistic approach not only optimizes space utilization but also enhances operational efficiency, ensuring maximum uptime. By consolidating various components into a unified system, the Vault room minimizes potential points of failure and streamlines maintenance procedures. Such a robust setup underscores the commitment to reliability, providing a resilient foundation for critical operations while prioritizing continuous functionality.
Vault Room: Total and certified protection
Certified
ABNT
NBR 15247
Assured quality
Certified
EN 1047-2
Assured quality
The Vault Room offers unparalleled protection, engineered to endure a wide array of threats such as fire, dust, water, smoke, gases, and beyond, in accordance with standards ABNT NBR 15.247 and EN 1047-2. These certifications ensure that the data center can withstand diverse threats, meeting rigorous requirements and guaranteeing unmatched security. Meticulously crafted with state-of-the-art technology and constructed to the most exacting quality standards, the Vault Room serves as the ultimate fortress for safeguarding critical data and systems, ensuring integrity and availability.
Addressing each risk vector individually is crucial to ensure comprehensive protection. It's important to assess the level of security provided by the Vault Room.
Flames:
Protection against flames + soak out - 900 min
Water:
Protection category IP x7
Dust:
Protection category IP 6x
Temperature:
does not exceed 75°C
Humidity:
does not exceed 85%
Unauthorized access:
Resistance class RC4
Corrosive comb. gases:
Total protection
Explosion:
Detonation test with 100kg TNT
Extinguishing water:
Total protection
EMC
EN 50147
1 GHz
23 - 57 dB
Falling debris:
Total protection -
impact energy of
3,000 Nm
Ballistic:
IIA Level
Environmental responsibility
Currently, Edgefy holds the Environmental Label certificate, confirming its concern and commitment to environmental preservation.
All waste generated during the installation of the Vault Room at the client's site is returned to the factory, where proper disposal is carried out for each type of waste.
Edgefy is fully committed to the environment and cares about all activities carried out inside and outside the factory. In this way, all waste generated in the manufacturing process of the Vault Room is directed to the appropriate location.
Our services
Edgefy operates throughout the entire process, from assessing the best solution for your organization to conducting risk analyses and facility assessments, all the way through to manufacturing, assembly, installation, and ensuring the solution's warranty.
Risk analysis
Facility analysis
Design and planning
Deployment and activation
All necessary certifications
Warranties
Contact us
+ 150
racks
+ 1,82
MW
III
Tier
1,4
PUE
Case SERPRO
Block building, modular, alta capacidade de processamento, escalável, infraestrutura de energia eficiente
Certificação NBR/ABNT 10636
O novo data center modular do SERPRO (Serviço Federal de Processamento de Dados) possui certificação conforme a norma NBR/ABNT 10636, atendendo aos critérios estabelecidos para garantir um ambiente protegido contra diversos riscos.
Tier III
Além de uma infraestrutura física robusta e resiliente, o Data Center possui certificação Tier III pelo Uptime Institute. Dessa forma é possível realizar manutenções concorrentes sem impactar no serviço para garantir a disponibilidade.
PUE 1,4
O data center modular do SERPRO tem um PUE de 1,4 que é altamente eficiente, consumindo apenas 40% da energia total para operações de suporte, como climatização. Esse desempenho reflete um design otimizado e sustentável, garantindo economia e alta performance operacional.
Planta baixa simplificada
O data center modular do SERPRO é formado por múltiplos containers e oferece uma infraestrutura completa e segmentada, garantindo eficiência e segurança. Com áreas separadas para front desk, NOC (Centro de Operações de Rede), data halls, salas elétricas, e uma usina de geradores, ele permite maior controle e gestão operacional. Essa estrutura modular também proporciona escalabilidade, permitindo que novos containers sejam integrados conforme a demanda cresce, além de oferecer alta resiliência por meio da segregação de sistemas críticos e operacionais.
